Multifold 30 2 Door Pack

Brio Multifold 30 Internal Bi-Fold Door Hardware – 2 Panel Pack (Without Track)

The Brio Multifold 30 is a versatile internal bi-fold door hardware system designed to deliver smooth operation, easy installation, and a refined finish for residential and light commercial applications. The pivot and hanger axes are positioned within 25mm of the door edge, reducing panel overhang and improving the overall appearance of the installed door system. This design also allows trim to be fitted, helping conceal the gap between the track and door panels.

The hanger system features four precision bearings and a quick-release plate for reliable performance and simplified installation. With convenient single spanner height adjustment, installers can achieve accurate door alignment with minimal effort.

This 2 panel pack of fittings is supplied without track, providing flexibility for custom track configurations.

Features

• Complete fitting pack for 2 internal bi-fold door panels
• Supplied without track
• Smooth and reliable folding door operation
• Pivot and hanger axis positioned close to the door edge for improved aesthetics
• Four precision bearings for enhanced performance
• Quick-release hanger plate for easy installation and maintenance
• Simple height adjustment using a single spanner
• Suitable for interior folding door applications

Specifications

• Product Class: Tracks
• Product Type: Internal Bi-Fold
• Maximum Panel Weight: 30kg
• Maximum Panel Height: 2400mm
• Maximum Panel Width: 650mm
• Minimum Panel Thickness: 19mm
• Height Adjustment: 3mm
• Horizontal Adjustment: 4mm
• Warranty: 10 Years
• Manufacturer Type: Manufacturer
