  3. FritsJurgens System M+ Axle Wrench – FJ500503
    By Bellevue Architectural

    FritsJurgens System M+ Axle Wrench – FJ500503

    $88.11
    $96.92 $88.11
    -9%
    Tax included. Shipping calculated at checkout.
    SKU: FJ500503
    $88.11
    $96.92 $88.11

    FritsJurgens FJ500503 Axle Wrench – System M+ Pivot Installation Tool

    The FritsJurgens FJ500503 Axle Wrench is a specialised installation tool designed for use with the FritsJurgens System M+ pivot system. It enables installers to rotate the oval spindle at the bottom of the System M+ pivot mechanism, helping position the spindle correctly during door installation.

    When installing a door fitted with the System M+ pivot system, it is important that the door is installed in its open position. The axle wrench allows the oval spindle to be rotated 90 degrees, with the arrow pointing towards the 0° position for mounting.

    Suitable for both new and existing projects, this tool assists with the installation and adjustment of large, heavy pivot doors fitted with the compatible System M+ system.

    Specifications

    • Brand: FritsJurgens.
    • Product Code: FJ500503.
    • Product Type: Axle Wrench / Pivot Installation Tool.
    • Compatibility: FritsJurgens System M+.
    • Function: Rotating the Oval Spindle of the Pivot Mechanism.
    • Spindle Rotation: 90 Degrees During Mounting.
    • Mounting Position: Arrow Aligned Towards the 0° Position.
    • Application: Pivot Door Installation and Adjustment.
    • Project Suitability: New and Existing Installations.

    Key Features

    • Specialised axle wrench for the FritsJurgens System M+ pivot system.
    • Designed to rotate the oval spindle at the bottom of the pivot mechanism.
    • Allows 90-degree spindle rotation during installation.
    • Assists with positioning the spindle arrow towards the 0° mounting position.
    • Supports correct installation of System M+ pivot doors.
    • Useful when working with large and heavy pivot doors.
    • Suitable for new installations and existing projects.
    • Provides a dedicated tool for compatible pivot system adjustments.

    Installation Instructions

    • Ensure the door is positioned open before installing the System M+ pivot mechanism.
    • Locate the oval spindle at the bottom of the System M+ unit.
    • Use the axle wrench to rotate the spindle 90 degrees as required.
    • Align the spindle arrow towards the 0° position for mounting.
    • Complete installation according to the FritsJurgens System M+ manufacturer's instructions.

    Available Variant

    • FJ500503 – Axle Wrench – System M+ Pivot Installation Tool.
