  3. 224 Exterior Plate With Cylinder Hole & Lever / Fixed / LH or RH
By Lockwood

224 Exterior Plate With Cylinder Hole & Lever / Fixed / LH or RH

$80.56 - $290.71
$155.48
$155.48
SKU: 22413NNSS
$155.48
$155.48

The Lockwood 224 Series Door Furniture features durable stainless steel plate construction with a modern square-end design. Concealed-fixed plates include internal-threaded studs positioned top and bottom, while visible-fixed plates incorporate matching countersunk holes for secure back-to-back installation through the door.

The Lockwood Overture Lever enhances the plate with its refined shape, offering a comfortable feel and a visually striking introduction.

Application

Designed for use with Lockwood 3770 Selector and 3570 Synergy Series Mortice Locks.

Features

  • Lever: Lockwood 59 (varies depending on selected variant)

  • External plate

  • Lever only

  • Cylinder pitch: 64mm

  • Fixing centres: 148mm

  • Concealed fixings

  • Non-handed

  • Stainless steel construction

  • Suits door thickness 35–45mm

  • For 45–55mm doors, specify long fixing screws SP2000-208

  • Supplied in trade pack

Dimensions

  • Height: 162mm

  • Width: 50mm

  • Depth: 2mm

Lever Dimensions

  • Length: 121mm

  • Projection: 57.5mm

  • Finger clearance: 51mm

Available Variants

  • Privacy Indicator – Emergency Turn Only

  • Cylinder Hole – Fixed Lever 144 – LH

  • Cylinder Hole – Fixed Lever 144 – RH

  • Cylinder Hole – Lever 102

  • Cylinder Hole – Lever 104

  • Cylinder Hole – Lever 144

  • Cylinder Hole – Lever 166

  • Lever 118

  • Lever 144

  • Lever 166

  • Privacy Indicator – Emergency Turn – Lever 101

  • Privacy Indicator – Emergency Turn – Lever 111

  • Privacy Indicator – Emergency Turn – Lever 112 – Selector

  • Privacy Indicator – Emergency Turn – Lever 118

  • Privacy Indicator – Emergency Turn – Lever 144

  • Privacy Indicator – Emergency Turn – Lever 166

  • Privacy Indicator – Emergency Turn – Lever 70 – Selector

  • Exterior Plate

  • Exterior Plate – Knob 20

  • Exterior Plate – Lever 59

  • Exterior Plate – Lever 77

  • Exterior Plate – Lever 90

  • Exterior Plate – Lever 96

  • Exterior Plate – Lever 98

  • Exterior Plate – Fixed Lever 96 – LH

  • Exterior Plate – Fixed Lever 96 – RH

  • Exterior Plate – Fixed Lever 98 – LH

  • Cylinder – Fixed Lever 70 – LH

  • Cylinder – Fixed Lever 70 – RH

  • Cylinder – Fixed Lever 90 – LH

  • Cylinder – Fixed Lever 90 – RH

  • Cylinder – Fixed Lever 96 – LH

  • Cylinder – Fixed Lever 96 – RH

  • Cylinder – Fixed Lever 97 – LH

  • Cylinder – Fixed Lever 98 – RH

  • Push Outline

  • Cylinder Hole – Lever 101

  • Cylinder Hole – Lever 104

  • Cylinder Hole – Lever 131

  • Cylinder Hole – Lever 178

  • Emergency Turn – Lever 104

  • Lever 104

  • Lever 166

  • Exterior Plate – Lever 123

  • Exterior Plate – Lever 96
